Manipulating G68 2 5 Axis Tilted Work Planes
Published at : September 29, 2021
This video explains how to move around features on a part with a G68.2 Tilted Work Plane Setup. It describes how to manipulate the sub-coordinate. I'm not a pro at this, but this video will give some insight into how this is done for others. Please save the comments about working in both metric and standard - it just is what it is.
This guy has a really great video that goes into MUCH more detail about Fanuc's G68.2 code: https://youtu.be/oifY95x2e7A
I think the reason that there is such variability between 3 mills and 3 similar fixtures is that there are minute differences between mills and tooling that add up to needing small changes to the feature positions.
This guy has a really great video that goes into MUCH more detail about Fanuc's G68.2 code: https://youtu.be/oifY95x2e7A
I think the reason that there is such variability between 3 mills and 3 similar fixtures is that there are minute differences between mills and tooling that add up to needing small changes to the feature positions.
